Jarrex Explosion Proof Jelly Jar Light
CLASS I DIVISION 1
The Jarrex Explosion Proof Jelly Jar Light is designed for a lumen output range of 2800 - 5600 lm. With their six mounting options, low maintenance and high efficiency, they provide operators with a valuable alternative to traditional hazardous location luminaries. Their special heat dissipating design, anti-vibration technology and Meanwell Driver & SMT LED chipset ensure a high lifespan with maximum lumen retention.
PRODUCT FEATURES
Classifications / Ratings
- Class I, Division 2, Groups A, B, C, D
- Class II, Division 1, Groups E, F, G
- Class II, Division 2, Groups F
- Class III
- Temperature Rating C1D2 T3
Product Details
| Efficacy (lm/W) | 140 lm/W |
| Power (W) |
Jarrex (G1L140) - 20 W, 30 W, 40 W |
| CCT (K) | 4000 K, 5000 K |
| CRI | 80 |
| Voltage | 100-277 V AC 50/60 Hz |
| Beam Angle | 120° (40°, 60°, 90°, can be made as per request) |
| Operating Temperature | -40° F to +200° F |
| IP Rating | IP66 |
| IK Rating | IK10 |
| Housing | Aluminum |
