Conall Linear Area Light
CLASS I DIVISION 2
Conall Linear Area Light is designed for use in hazardous locations where flammable gases or vapors, flammable liquids and other ignitable materials exist. Its rugged design and efficient heat dissipation stands up to challenging conditions while ensuring long life and high lumen performance. This fixture utilizes a premium Meanwell Driver & SMT LED chipset to achieve high efficacies.
PRODUCT FEATURES
Classifications / Ratings
- Class I, Division 2, Groups A, B, C, D
- Class II, Division 1, Groups E, F, G
- Class II, Division 2, Groups F, G
- Class III
- II 2 G Ex db eb mb IIC T5/T6 Gb
- II 2 D Ex tb IIIC T95°C/T85°C Db IP66
- Ex db eb mb IIC T5/T6 Gb
- Ex tb IIIC T95°C/T85°C Db
- Temperature Rating C1D2 T5 / T6
Product Details
| Efficacy (lm/W) | 140 lm/W |
| Variant & Power (W) |
Conall 2 (R2L140) - 20 W, 30 W, 40 W Conall 4 (R4L140) - 40 W, 50 W, 60 W |
| CCT (K) | 4000 K, 5000 K |
| CRI | 80 |
| Voltage | 100-277 V AC 50/60 Hz |
| Beam Angle | 120° |
| Operating Temperature | -40° F to +140° F |
| IP Rating | IP66 |
| IK Rating | IK08 |
| Housing | Stainless-steel |
