Victoris Explosion Proof Linear High Bay
CLASS I DIVISION 2
The Victoris Linear High Bay is designed for use in hazardous facilities and provides its operators with a powerful & efficient alternative to traditional hazardous location luminaries. Its compact design makes this fixture an excellent replacement upgrade option for bulky & high maintenance fixtures. The copper-free aluminum-alloy body is powder coated for added durability & attractive aesthetic appearance. Special heat dissipating design in conjunction with anti-vibration technology ensures high lifespan with maximum lumen retention. This fixture utilizes a premium Meanwell Driver & SMT LED chipset to achieve high lumens.
PRODUCT FEATURES
Classifications / Ratings
- Class I, Division 2, Groups A, B,C, D
- Class II, Division 1, Groups E, F, G
- Class II, Division 2, Groups F, G
- Class III
- Il3 G Ex ec IIC T5/T6 Gc
- Il2 D Ex tb IIIC T80/100°C Db IP66
- Temperature Rating C1D2 T5 / T6
Product Details
| Efficacy (lm/W) | 140 lm/W |
| Variant & Power (W) |
Victoris 2 (H2L140) - 20 W, 40 W Victoris 4 (H4L140) - 40 W, 60 W, 80 W |
| CCT (K) | 4000 K, 5000 K |
| CRI | 80 |
| Voltage | 100-277 V AC 50/60 Hz (200-480 V fixtures also available) |
| Beam Angle | 120° |
| Operating Temperature | -40° F to +200° F |
| IP Rating | IP66 |
| IK Rating | IK08 |
| Housing | Aluminum |
