Spelta
Corn Bulb
The IKIO Spelta Corn Bulb is designed for direct replacement of existing CFL and HID lamps. These lamps are offered in a variety of color temperatures for flexibility in all types of applications. Available options of frosted and clear lens allow for an evenly illuminated glow, resembling traditional bulbs.
PRODUCT FEATURES
- Low energy consumption as compared to traditional bulbs, which makes them environment friendly.
- Even light distribution due to its 360° optical design.
- Protection from High Voltage Surge (6KV).
- Superior hollow heat sink for much improved heat management.
- Exceptional lumen output and lighting quality.
- Comes with silicone gaskets.
Product Details
| Efficacy (lm/W) | 120 lm/W |
| Power (W) | 14 W, 27 W, 36 W, 45 W, 54 W, 60 W |
| CCT (K) | 3000 K, 3500 K, 4000 K, 5000 K |
| CRI | 80+ |
| Voltage | AC 100-277 V 50/60 Hz |
| Beam Angle | 360° |
| Dimming | No |
| Operating Temperature | -20.2° F to +140° F |
| IP Rating | IP64 |
| Housing | Aluminum + Polycarbonate |
Technical Resources
Product Sheet
LM79 Reports
Installation Instructions
SKU Details
| Power | SKU Number | CCT | Voltage | Lumen Output | Beam Angle | Dimming | Diffuser | Qualified part number | Ordering part number | Technical Data Sheet | IES File |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 14 W | 662187544229 | 3000 K | AC 100-277 V | 1680 lm | 360° | Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0014-E(X)3930 | Download | On Request |
| 14 W | 662187544236 | 3500 K | AC 100-277 V | 1680 lm | 360° | Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0014-E(X)3935 | Download | On Request |
| 14 W | 662187544243 | 4000 K | AC 100-277 V | 1680 lm | 360° | Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0014-E(X)3940 | Download | On Request |
| 14 W | 662187544267 | 5000 K | AC 100-277 V | 1680 lm | 360° | Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0014-E(X)3950 | Download | On Request |
| 27 W | 662187546971 | 3000 K | AC 100-277 V | 3240 lm | 360° | Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0027-E(X)3930 | Download | Download |
| 27 W | 662187547114 | 3500 K | AC 100-277 V | 3240 lm | 360° | Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0027-E(X)3935 | Download | Download |
| 27 W | 662187547121 | 4000 K | AC 100-277 V | 3240 lm | 360° | Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0027-E(X)3940 | Download | Download |
| 27 W | 662187554891 | 5000 K | AC 100-277 V | 3240 lm | 360° | Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0027-E(X)3950 | Download | Download |
| 36 W | 662187546926 | 3000 K | AC 100-277 V | 4320 lm | 360° | Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0036-E(X)3930 | Download | Download |
| 36 W | 662187546933 | 3500 K | AC 100-277 V | 4320 lm | 360° | Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0036-E(X)3935 | Download | Download |
| 36 W | 662187546940 | 4000 K | AC 100-277 V | 4320 lm | 360° | Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0036-E(X)3940 | Download | Download |
| 36 W | 662187557274 | 5000 K | AC 100-277 V | 4320 lm | 360° | Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0036-E(X)3950 | Download | Download |
| 45 W | 662187546780 | 3000 K | AC 100-277 V | 5400 lm | 360° | Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0045-E(X)3930 | Download | Download |
| 45 W | 662187546797 | 3500 K | AC 100-277 V | 5400 lm | 360° | Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0045-E(X)3935 | Download | Download |
| 45 W | 662187546803 | 4000 K | AC 100-277 V | 5400 lm | 360° | Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0045-E(X)3940 | Download | Download |
| 45 W | 662187546827 | 5000 K | AC 100-277 V | 5400 lm | 360° | Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0045-E(X)3950 | Download | Download |
| 54 W | 662187546858 | 3000 K | AC 100-277 V | 6480 lm | 360° | Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0054-E(X)3930 | Download | Download |
| 54 W | 662187546865 | 3500 K | AC 100-277 V | 6480 lm | 360° | Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0054-E(X)3935 | Download | Download |
| 54 W | 662187546889 | 4000 K | AC 100-277 V | 6480 lm | 360° | Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0054-E(X)3940 | Download | Download |
| 54 W | 662187503851 | 5000 K | AC 100-277 V | 6480 lm | 360° | Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0054-E(X)3950 | Download | Download |
| 60 W | 662187546582 | 3000 K | AC 100-277 V | 7200 lm | 360° | Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0060-E(X)3930 | Download | On Request |
| 60 W | 662187546599 | 3500 K | AC 100-277 V | 7200 lm | 360° | Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0060-E(X)3935 | Download | On Request |
| 60 W | 662187546605 | 4000 K | AC 100-277 V | 7200 lm | 360° | Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0060-E(X)3940 | Download | On Request |
| 60 W | 662187546629 | 5000 K | AC 100-277 V | 7200 lm | 360° | Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0060-E(X)3950 | Download | On Request |
| 14 W | 662187462868 | 3000 K | AC 100-277 V | 1680 lm | 360° | Not Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0014-E(X)3930 | Download | On Request |
| 14 W | 662187462875 | 3500 K | AC 100-277 V | 1680 lm | 360° | Not Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0014-E(X)3935 | Download | On Request |
| 14 W | 662187462882 | 4000 K | AC 100-277 V | 1680 lm | 360° | Not Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0014-E(X)3940 | Download | On Request |
| 14 W | 662187462899 | 5000 K | AC 100-277 V | 1680 lm | 360° | Not Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0014-E(X)3950 | Download | On Request |
| 27 W | 662187462905 | 3000 K | AC 100-277 V | 3240 lm | 360° | Not Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0027-E(X)3930 | Download | Download |
| 27 W | 662187462912 | 3500 K | AC 100-277 V | 3240 lm | 360° | Not Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0027-E(X)3935 | Download | Download |
| 27 W | 662187462929 | 4000 K | AC 100-277 V | 3240 lm | 360° | Not Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0027-E(X)3940 | Download | Download |
| 27 W | 662187462936 | 5000 K | AC 100-277 V | 3240 lm | 360° | Not Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0027-E(X)3950 | Download | Download |
| 36 W | 662187462943 | 3000 K | AC 100-277 V | 4320 lm | 360° | Not Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0036-E(X)3930 | Download | Download |
| 36 W | 662187462950 | 3500 K | AC 100-277 V | 4320 lm | 360° | Not Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0036-E(X)3935 | Download | Download |
| 36 W | 662187462967 | 4000 K | AC 100-277 V | 4320 lm | 360° | Not Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0036-E(X)3940 | Download | Download |
| 36 W | 662187462974 | 5000 K | AC 100-277 V | 4320 lm | 360° | Not Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0036-E(X)3950 | Download | Download |
| 45 W | 662187462981 | 3000 K | AC 100-277 V | 5400 lm | 360° | Not Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0045-E(X)3930 | Download | Download |
| 45 W | 662187462998 | 3500 K | AC 100-277 V | 5400 lm | 360° | Not Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0045-E(X)3935 | Download | Download |
| 45 W | 662187463001 | 4000 K | AC 100-277 V | 5400 lm | 360° | Not Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0045-E(X)3940 | Download | Download |
| 45 W | 662187463018 | 5000 K | AC 100-277 V | 5400 lm | 360° | Not Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0045-E(X)3950 | Download | Download |
| 54 W | 662187463025 | 3000 K | AC 100-277 V | 6480 lm | 360° | Not Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0054-E(X)3930 | Download | Download |
| 54 W | 662187463032 | 3500 K | AC 100-277 V | 6480 lm | 360° | Not Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0054-E(X)3935 | Download | Download |
| 54 W | 662187463049 | 4000 K | AC 100-277 V | 6480 lm | 360° | Not Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0054-E(X)3940 | Download | Download |
| 54 W | 662187463056 | 5000 K | AC 100-277 V | 6480 lm | 360° | Not Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0054-E(X)3950 | Download | Download |
| 60 W | 662187463063 | 3000 K | AC 100-277 V | 7200 lm | 360° | Not Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0060-E(X)3930 | Download | On Request |
| 60 W | 662187463070 | 3500 K | AC 100-277 V | 7200 lm | 360° | Not Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0060-E(X)3935 | Download | On Request |
| 60 W | 662187463087 | 4000 K | AC 100-277 V | 7200 lm | 360° | Not Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0060-E(X)3940 | Download | On Request |
| 60 W | 662187463094 | 5000 K | AC 100-277 V | 7200 lm | 360° | Not Dimmable | Clear | Not Qualified Yet | IK-CRA-L120-0060-E(X)3950 | Download | On Request |
